Excellent-P/PH系列测量机

Excellent-P/PH系列测量机是专为测量超高精度、超复杂零部件而研发的产品,为医疗器械、卫星制造、航空发动机、叶片、汽车精密部件等领域产品的测量提供了可靠的解决方案。


Excellent-P/PH系列测量机采用高精度光栅,控制系统及温度补偿技术可配置扫描测头或Revo测头,同时可以配置全自动机械手,自动上下料系统,给出精确的测量结果,让复杂的超高精度零部件制作或工艺测量变得流畅精确。

Excellent- P/PH系列测量机可应用于医疗器械、航空航天、汽车部件、电子部件等领域。



型号行程范围主机外廓尺寸允许工件尺寸系统净重被测工件最大重量3D最大速度3D最大加速度
MODELSTROKESOVERALL SIZEWORK ENVELOPEWEIGHTPART WEIGHT3D Max Speed3D Max Accelerate Speed
XYZLxLyLzWxWyWz
mmmmmmmmmmmmmmmmmmkgkgmm/smm/s²
NCE564500600400110011340224062510956007205008001900
NCE68660080060012001650266073014008009807008001900
NCE810680010006001400185026609301600800129010008001900
NCE815680015006001400235026609302100800162010008001800
NCE91289001200800159023703150109018141040223018005801800
NCE101261000120060016902370280011501814700235018005801800
NCE1012810001200800169023703150119018141040249018005801800
NCE1015810001500800169026703150119021141040258018005801800
NCE1020810002000800349067704370235055001690344018005801800
NCE1215101200150010003490XX43702350XX1690337020005001100
NCE122010120020001000399047704370285035001690395020005001100
NCE152010150020001000399057704370285045001690526030005001100
NCE152512150025001200399067704370285055001690677030004501100
NCE1530101500300010003990XX43702850XX1690816030004501100
NCE153512150035001200349047705370235035002100925030004501100
NCE1525151500250015003490XX53702350XX210070003000400900
NCE15301515003000150039906770497028505500195084903000400900
NCE163515160035001500399077704970285065001950100103000400900
NCE18251018002500100039904770537028503500210084903000400900
NCE18XX101800XX10003990XX53702850XX2100XX3000400900
NCE203015200030001500499077705370335065002100112503000400900


  • MPEE:自0.7μm起
  • 电源电压(Power Voltage):220V
  • 温度范围(Temperature Range):19-21℃/15°C-26℃
  • 空气压力(Air Pressure):0.5-1.0Mpa
  • 温度变化(Hourly Temperature Cycle):0.5℃/h
  • 过滤精度(Filter Accuracy):0.3μm
  • 温度梯度(Thermal Gradient):0.5℃/m
  • 空气流量(Air Supply):0.12-0.45m³/min
  • 湿度范围(Relative Humidity):25%-75%
